Type of illuminant： 650nnm laser?( safe visible light )
Supported interfaces： RS232 / PS2 keyboard / USB Support HID SPP protocol
Decode Capability： Code 39,?Full ASCⅡ, Code bar,?Industrial 2 of 5,?Interleave 2 of 5,?Matrix 2 of 5,?Code 93,?Code 128,?Code 32,?Standard code 39,?EAN?128,? MSI,? EAN?8&13,? UPCA & E,? Plessey,? Databar14, TELEPE, GSI Databar
Precision： ≥3 mil (0.076 mm)
Operation： Manual/Automatic ( auto-induction )
Depth of scan field： 10-800mm
Decode speed： 200 times/second
Light intensity ：Daylight, 3000-80000Lux Max
Decode error rate： Less than 1/8 million
Print Contrast Signal： ≥20°
scan angle： Yaw(Skew)65° & Pitch60°
Industrial Grade： IP67, 7 meters Drop Test
Safety： Full quakeproof, waterproof, dustproof, antiknock-design and EMI Shielding
Mechanical/Electrical
Power voltage： DC 5V
Current ：Operation 85mA; Idle 36mA
Scanner Material： ABS+PC, Flameresistant material
Physical
Exterior dimension： L*W*H (mm): 169*70*100
Materials： Plastic
Weight： 235g
Environment
Operating humidity： 5%-95%
Storage humidity： 5%-95%
Operating temperature： -20°C-50°C
Storage temperature： -20°C-60°C
Safety performance： ROHS class 2 laser product, FCC class B and CE
