Type of illuminant    ：650nnm?laser(visible)

Operation：    Manual

Depth of scan field：       10-800mm

Decode speed 120：times/second

Precision：      0.1mm (4 mil)

Decode error rate：        Less?than?1/5?million

Supported interfaces：   USB (standard), RS232 (optional),PS/2 (optional)

Scan angle：   Yaw(Skew)45°&?Pitch60°

Decode  Capability:Code39Full ASC II,Code bar,Industrial 2 of 5,Interleave 2 of 5,Matrix 2 of 5,Code 93,Code 128,Code 32,Standard code 39,EAN 128,MSI,EAN 8&13,UPCA&E,Plessey,Databar14,TELEPE

Eelectrical

Power voltage :DC 5V

Working current:120mA

Static current: :10mA

Physical

Exterior dimension: L*W*H?(mm):?170*70*100

Materials:        Plastic

Weight     :235g

Environmetal

Operating humidity :5%-85%

Storage humidity     :5%-85%

Operating temperature: -20°C-45°C

Storage temperature:     -20°C-45°C

Safety performance:        ROHS  class  2  laser  product, FCC  class B and CE

Applicable scope

Comercial POS system(Supermarkets)

Warehousing and logistics

Libraries

Banks and Telecom

Transportaion

Postal service

Industrial and manufacturing management
