Detail Specification
Interfaces:USB Port
Print Comand :ESC/POS
Print Method:Thermal Line Printing
Pirnt Speed :90mm/sec
No. of Total Dots:384 dots/Line
Print Font:12 x 24; 24x 24
Character Set :Alphanumeric /Chinese Kanji
Data Buffer :UP to 5K bytes
Data Buffer :UP to 5K bytes
Compatible OS:Win9X/Win2000//Win2003/Win Vista/ Win 7/Window XP /Win 8.1/Win10/linux/Android
Compatible with ESPON,SAMSUNG
Paper
Type:Roll Paper
Width :57.5±0.5mm
Roll Diameter :75mm
Paper Thickness :0.06-0.08mm
Electrical
Adapter Voltage:DC12V/3A
Cash Drawer Control:12V/1A
Print Head :Reliability
Print Reliability :100km
Physical
Dimension:175*130*110mm
Unit Weight :1.2kgs
Pieces Per CTN :18 Pieces
Color :Black and White
CTN Dimension:48.5 x 41.5 x 26.5 cm
Carton Weight :18kgs
Environmental
Temperature:Working: 0 to 45 Degrees
Humidity:Working: 10%-80%
Warantty :12 months at least
Other Features:High speed and low noise, owing to line thermal print; Built-in adaptor
Accessories
USB Cable:1 x 1M Cable
CD Driver :1 Piece
Thermal Roll:1 Piece
Manual:1 Piece
Power Cable :1 Piece
